Electroplating System Machine - copper, nickel, gold, silver, rhodium, platinum plating

Sold by NLDT
+ $54.80 shipping
+ $54.80 shipping
In stock
Preparation takes 3-5 business days
Arrives from United Kingdom
Returns and exchanges accepted
See this seller's return policy

Made in London, United Kingdom

Item details

Technical specification:

-Input: 110V-240Vac;
-Current: 0-2 ADC for all continuously and accuracy electroplating processes;
-Regulated voltage – 1.6-12 Vdc;
-Anode and cathode 4-mm contact rods;
-Three water’s heating plastic tanks (50 ml each);
-Plating-Stripping option;
-Solution heating option;
-Air agitation option;
-SS316, copper and nickel anodes (strips dimensions in iches (mm): 1″x4″ (25×100) for cleaning process & for copper, nickel, gold, silver, rhodium and platinum plating);
-Dimensions of the unit in inches (mm): 7″(W)x6″(D)x6″(H) (175(W)x150(D)x150(H));
-Tank dimensions in inches (mm): 2″(D) x 2.1/2″(H) (50 diam x 63 high);
-Biggest forming/plating object’s dimensions is about 1.1/2 sq.inch (40 mm);
-Copper chemicals to make 50 ml of plating solution for testing purpose;
-Downloadable Electroplating course for beginners on similar unit;
-Biggest plating area – 4 sq. inch:
-Overload automatic power cut-off system;
-Beige polypropylene plastic welded enclosure;
-Traditional design;
-Weight – 1 kg.

Delivery specification:

– The compact electroplating unit;
– 2 x anode and cathode 4 mm stainless steel rods;
– High purity SS, copper and nickel anode strips for different plating processes;
– 3 x protective plastic mesh for the anode strips;
– 3 tanks 50 ml each with lids;
– Copper plating chemicals for 50 ml of solution for testing purpose;
– Downloadable User manual with an electroplating course for beginners;
– One year manufacturer warranty.


Note: Your valid phone number is very important for the shipping,please provide it when you order!

    Average review
    Mar 13, 2017 by The Hairy Jewellers
    Quick shipping. It's ok. Pricey and small plus, it leaks water. Had to seal the plastic weld. No on/off switch. They claim it's for safety but all my other plating systems have one.
    Feb 7, 2017 by Kurt Randolph
